Run your own personal cloud storage and enjoy easy file access, sharing, and syncing with the TS-433. Designed with a 2.5GbE port to enhance collaboration and increase remote work productivity, the TS-433 also features rich multimedia applications and provides a complete home entertainment portal.
Centrally store photos, music, and videos; easily browse, organize, and share multimedia files.
With a built-in NPU (Neural network Processing Unit) processor, the TS-433 boosts performance for high-speed face and object recognition.
Supports ARM NEON technology that accelerates video processing for a greater entertainment experience.
myQNAPcloud allows you to easily access, manage, and share NAS files via the Internet.
Protect your files and data from accidental deletion and malware attacks by using advanced snapshot protection.
Serves as a secure private cloud and supports user account protection, IP blocking, 2-step verification, encryption access, and more.
Specifications:
| CPU | ARM 4-core Cortex-A55 2.0GHz processor |
| CPU Architecture | 64-bit ARM |
| Graphic Processors | Mali-G52 |
| Floating Point Unit | |
| Encryption Engine | |
| Hardware-accelerated Transcoding | |
| Neural Processing Unit (NPU) | |
| System Memory | 4 GB on board (non-expandable)
Note: Reserves some RAM for use as shared graphics memory.
|
| Maximum Memory | 4 GB on board (non-expandable) |
| Flash Memory | 4 GB (Dual boot OS protection) |
| Drive Bay | 4x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | |
| Gigabit Ethernet Port (RJ45) | 1 |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 1 (2.5G/1G/100M) |
| Wake on LAN (WOL) | |
| Jumbo Frame | |
| USB 2.0 port | 2 |
| USB 3.2 Gen 1 port | 1 |
| Form Factor | Tower |
| LED Indicators | System Status, LAN, USB, HDD1~4 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 165 × 160.2 × 220.5 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) | 2.07 kg |
| Weight (Gross) | 3.39 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | Minimum 65W adapter (12VDC), 100-240VAC |
| Power Consumption: Disk Standby Mode | 8.45 |
| Power Consumption: Operating Mode, Typical | 22.54 W
Tested with drives fully populated.
|
| Fan | 1 x 120mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | |
| Standard Warranty | 2 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 200 |
| Operating System |
QTS 5.2.3 |
| Supported Client Operating Systems |
|
| Supported Browsers |
|
| Supported Languages |
Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, and Turkish |
| Storage Pool |
|
| SED Storage Pool |
|
| Maximum Pool size |
308 TB |
| Maximum number of storage pool |
128 |
| Volume Type |
Thick, Thin, Static |
| Maximum volume size |
250 TB Note: At least 4 GB RAM is required. |
| Maximum number of volume |
128 |
| Maximum shared folder size |
250 TB |
| Maximum number of shared folder |
512 |
| JBOD Expansion |
|
| VJBOD / VJBOD Cloud |
|
| iSCSI Service |
|
| LUN Type |
Thick, Thin |
| File-based iSCSI LUN |
|
| Block-based iSCSI LUN |
|
| Maximum LUN size |
250 TB Note: At least 4 GB RAM is required. |
| Maximum number of targets LUN |
128 |
| LUN feature |
|
| Auto Tiering |
Requires minimum 2GB memory. |
| RAID Type |
|
| RAID Group |
To ensure data security, system stability, and storage performance, the maximum number of drives for a single RAID group is now 16 (applicable to RAID 5, RAID 6, RAID TP, and subgroups of RAID 50 and RAID 60). Nevertheless, users can combine multiple RAID groups into a large storage pool that contains more than 16 drives, using RAID 50, RAID 60, or RAID 10 as the RAID configuration. This enhancement will only be applied to new RAID groups. All existing RAID groups and storage systems will not be affected. |
| RAID Level Migration |
|
| RAID Expansion (by adding Disk) |
|
| RAID Expansion (by replacing bigger Disks) |
|
| Storage Pool Expansion (by adding RAID Group) |
|
| RAID Hot Spare |
Global, Local |
| RAID Sync/Rebuild/Scrubbing |
|
| Internal drive |
EXT4 |
| External drive |
EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT (optional for ARM model) Note: To use exFat in certain models you must purchase an exFAT driver license from License Center. |
| Disk, Enclosure Locate |
|
| Disk S.M.A.R.T. Scan |
|
| Disk S.M.A.R.T. Data Migration |
|
| Ironwolf Health Management |
|
| Secure Erase |
|
| SSD Trim |
|
| SSD Life Estimation |
|
| Disk Roaming |
|
| Disk Standby |
|
| Volume Snapshot |
|
| LUN Snapshot |
|
| Maximum Snapshot (Per System) | |
| Maximum Snapshot (Per Volume / LUN) | |
| Minimum Snapshot Interval |
5 minutes |
| Snapshot Retention Policy |
|
| Self-serve Snapshot Recovery |
|
| Application Consisted Snapshot |
|
| Snapshot Full Clone |
|
| Snapshot Replica / Vault |
|
| SSD profiling tool |
|
| External Device Management |
|
| Mount Smart Phone (MTP) |
|
| External RAID Device (QNAP so on) Management (External Device Mode) |
|
| External RAID Device (QNAP so on) Management (NAS Mode) |
|
| File Server |
|
| FTP Server |
|
