| Display |
|
 |
|
| Display: |
15.6" FHD (16:9) Anti-Glare Matte-Type Screen (1920x1080) |
| |
|
| Processor |
|
|
|
Processor:
Chipset: |
4th Generation Intel® Mobile Core i7-4710MQ Haswell Processor (Upgradeable)
Intel® HM87 Chipset |
| |
|
| HDD & ODD Drives |
|
|
|
Standard Hard Drive:
Standard Optical Drive:
|
512GB Crucial® M550 mSATA SSD + 1TB 7200RPM Hard Drive (Upgradeable)
2 Detachable 2.5" 9.5mm (H) SATA Hard Disk Drives + Coexisting 2 x mSATA SSDs
Raid 0/1 Supported
6x Blu-Ray Reader + 8x DVDRW/CDRW Super Multi Combo Drive (Upgradeable)
1 12.7mm (H) Optical Drive Bay, ATA Interface, Interchangeable with ±R/RW Combo drive |
| |
|
| Graphics |
|
|
|
| Graphics Controller: |
NVIDIA® GeForce GTX 980M GDDR5 (8.0GB) w/ Optimus Technology (Upgradeable)
PCI-Express™ 16X
Microsoft® DirectX® 11 |
| |
|
| Memory |
|
|
|
Standard Memory:
Number of SODIMMS:
|
8,192MB (8GB) DDR3 1600MHz (Upgradeable - 32GB* 1600MHz Max)
Four 204Pin SODIMM Sockets
*Windows 7 Pro or Higher Operating System Required for 32GB Ram Configuration |
| |
|
| Audio Features |
|
|
|
| Audio Features: |
High Definition audio interface
1 x S/PDIF digital output
1 x Built-in Microphone
2 x Built-in Speakers
1 x Built-in Sub-woofer
External 7.1CH audio output supported by headphone, microphone, S/PDIF and Line-in jack
Sound Blaster® X-Fi™ MB 3
Amplified Headphone output |
| |
|
| Network |
|
|
|
Network / Communication:
|
Built-in Gigabit Ethernet LAN
Bigfoot Killer™ Wireless-N 1202+ Bluetooth Combo Card |
| |
|
| Slots / Interface |
|
|
|
Card Reader:
Input / Output Ports: |
3 x Mini-Card Slot for WLAN
1st for WLAN Combo module (Half size Mini Card with PCIe and USB interface)
2nd and 3rd slots for mSATA SSD Full size Mini Card with SATA interface
9-in-1 Card Reader
MMC / RSMMC / MS / MS-Pro / MS-Duo / SD / Mini-SD / SDHC / SDXC
1 x HDMI output Port (with HDCP)
1 x DisplayPort 1.2 output Port
1 x Mini DisplayPort 1.2
1 x USB 2.0 Port
3 x USB 3.0 Ports (One powered USB port, AC/DC)
1 x eSATA Port (USB 3.0 combo)
1 x Mini-IEEE 1394a Port
1 x Headphone Jack
1 x Microphone Jack
1 x S/PDIF output Jack
1 x Line-in Jack
1 x RJ-45 LAN (10/100/1000Mbps) |
| |
|
| Power System |
|
|
|
Battery:
Input/Output: |
8 Cells Lithium Ion Battery Pack (76.96Wh)
Full Range 180W AC-In 100-240 V AC, 50/60Hz Universal | DC Output: 19.5V, 9.2A -or- 19V, 9.5A AC Adapter |
| |
|
| Cooling |
|
|
|
Standard Cooling:
Optional Cooling: |
Copper CPU Heatsink
IC Diamond Thermal Compound |
| |
|
| Size & Weight |
|
|
|
Size:
Weight: |
14.76" (w) x 10.55" (d) x 1.73" (h)
7.28 lbs with 8-cell Battery |
| |
|
| Keyboard / Point Device |
|
|
|
Keyboard:
Point Device: |
Full Sized Illuminating Keyboard with Numeric Key Pad
W / A /S /D Gaming Keys
Integrated Touchpad with Scrolling Function & Multi-gesture |
| |
|
| Additional Features |
|
|
|
| Extra Features: |
Built-in 2.0M FHD Video Camera
Intel® Rapid Start Technology
Intel® Smart Response Technology
Intel® Smart Connect Technology
Intel® Anti-Theft Technology
Rubber Painting |
| |
|
| Operating System |
|
|
|
Standard OS:
|
No Operating System Standard (Windows® 7 & 8.1 Available) |
